Inspire – Mirror Infrared Heater

What size panel do I need?use our Wattage estimator

Watts Panel size cm Heated area
250 60 x 30 3 - 5 m2
350 90 x 30 4 - 7 m2
420 60 x 60 5 - 8 m2
550 80 x 60 7 - 12 m2
750 90 x 70 11 - 18 m2
900 100 x 80 13 - 22 m2
1250L 160 x 60 (for dwarf walls) 17 - 29 m2

FROM $1,249.00

Clear

Next Day Delivery
DIY Friendly
Reduce heating Cost
Highly energy efficient
10 Warranty
Zero maintenance

Description

HERSCHEL MIRROR heating panels are an ideal addition to your bathroom, hallway, or to the reception area or lobby of a corporate building, combining sophisticated design with optimum safety and energy efficiency.

All units are made with Mirror Safety Glass and manufactured in Germany from the highest quality materials and are guaranteed for 10 years. Infrared mirror heater panels can be placed in humid areas such as bathrooms without any condensation forming on the glass, whilst also chasing away the causes of moisture that other heater types actually encourage (hot air moving over a cold surface).

Due to the infrared heating process, the mirrors heat up objects in the room rather than the air. This helps keep bathroom walls and fittings warm, dry and free of mould.

Available in seven different sizes and power outputs from 250 – 1250 Watts to suit every requirement, Herschel Inspire heaters operate at a fraction of the cost of traditional heating, but offer higher thermal comfort levels.

Click here to download the Data Sheet.

Click here to download Installation & Operating Instructions.

The heated areas are a guide only and assume a medium to well insulated space with an average floor to ceiling height of 2.40M.  If room heights are greater or there are other building factors to consider then please contact us for a more exact quote using the Customer Service form or contact your dealer directly so that a more detailed assessment can be carried out.

Technical Details

Field of application: Direct Heating
Surface: ESG Mirror Safety Glass
Rear-panel: Sheet steel, powder coated, with mounting points
Surface temperature: 85 – 95°C
Voltage: 230V 50hz
Protection Class: IP54
Installation: Wall mounted

Quality & Safety

CE

TÜV GS Certification (by TÜV Rheinland, Germany)

EMC Certification (by TÜV Rheinland, Germany)

RoHS compliant

Made in Germany

Guarantee: 120 months

Inspire Certifications
